OVER IP VGA 8 Ports

1U Rack-Mountable
VGA Port
USB2.0
3 Switch method
1920×1080@30-60Hz

Send Email Get Price

Product Overview Product Features Parameter Related Product Contact us

Product Overview

The 1008IPVGA rack-mountable USB KVM switch allows access and control of up to 8 computers from a single console (keyboard, mouse, and monitor). By cascading to an additional 7 additional switches, up to 256 computers can be controlled from a single keyboard and mouse console.

Support resolutions up to 1920x1080; DDC2B. Switching between computers can be easily done through front panel buttons, keyboard hotkey combinations, or on-screen display (OSD).

The rack-mounted KVM switch supports USB connections for the console and computers, allowing for the connection of an additional VGA display.

Product Features

Standard 19-inch rack installation, occupying only 1U rack space.
Standard VGA connection - Connect to servers or computers through standard VGA connectors.
Supports computers with USB keyboards and mice.
Convenient computer switching is achieved through front panel buttons, keyboard hotkey combinations, or on-screen display (OSD).
Automatic scanning function, used to monitor the computer selected by the user.
Hot plug - You can add or remove computers without shutting down the switch.
By naming the server and entering the SN number in a fuzzy manner, you can quickly locate and select the server security features you need.
A single group of control terminals manages 8 servers
Can cascade multiple devices and manage up to 256 computers
Support multi-user account management and management level, password protection and search PC server name
High brightness, high definition, resolution up to 1920x1080@60Hz
Support various operating systems：Dos/Windows series, Linux, Unix Mac OS 8.6/9/10, SUN Solaris 8/9

Parameter

Model			HL-1732(4IP)	HL-1764(4IP)
Control port			1 Local, 4 Remote
Port Selection			Buttons, OSD menu, Hotkeys, UI, Web
Connector	Console	Monitor	1 * HDB-15 Female
		Keyboard	3 * USB TYPE A	3 * USB TYPE A & 2 * PS2
		Mouse
	KVM port (RJ45)		32	64
	Remote Console (RJ45)		2（1*Redundant）
	Power		2 * 3-Prong AC socket
Input power			110V- 240Vac, 50-60Hz
			Redundant Hot-Swappable Power Supplies * 1
LCD Monitor	LCD type		FHD TFT
	View area		17.3＂
	Optimum resolution		1920*1080@60Hz
	Display color		16.7M
	Brightness		220cd/m² (Typ)
	Contrast ratio		1000: 1 (Typ)
	Pixel pitch(mm)		0.1989(H) × 0.1989(V)
Mouse	X/Y resolution		>1000 points /inch, (40 points/mm)
	Scroll wheel		Supports scroll wheel function
Keyboard			104 keys
			(87 keys main keyboard +17 independent small numeric keyboard)
Power Consumption			65W
Operating Temperature			,-10℃~60℃
Storage Temperature			,-30℃~70℃
Humidity			0 – 80% RH, non - condensing
